产品详情：
型号尺寸及参数
|
型号 |
箱体安装尺寸BxAxH(mm) |
过滤器尺寸(mm) |
额定 风量 (m3/h) |
进风管尺寸 DxC(mm) |
风管链接尺寸 ExF(mm) |
箱体外形尺寸TxSxR(mm) |
重量(KG) |
|
KHB320F |
370x370x220 |
320x320x80 |
360 |
200x200 |
250x250 |
430x430x268 |
≈12 |
|
KHB350 F |
400x400x220 |
350x350x80 |
450 |
200x200 |
250x250 |
460x460x268 |
≈14 |
|
KHB400 |
450x450x220 |
400x400x80 |
500 |
200x200 |
250x250 |
510x510x268 |
≈15 |
|
KHB484 |
530x534x220 |
484x484x80 |
800 |
320x200 |
370x250 |
594x594x268 |
≈16 |
|
KHB550 |
600x600x220 |
550x550x80 |
1000 |
320x200 |
370x250 |
660x660x268 |
≈17 |
|
KHB610 |
660x660x220 |
610x610x69 |
1000 |
320x250 |
370x300 |
720x720x268 |
≈18 |
|
KHB820 |
870x650x220 |
820x600x69 |
1300 |
320x250 |
370x300 |
930x710x268 |
≈20 |
|
KHB630 |
680x680x220 |
630x630x80 |
1500 |
320x250 |
370x300 |
740x740x268 |
≈22 |
|
KHB726 |
776x534x220 |
726x484x80 |
1200 |
400x200 |
450x250 |
836x594x268 |
≈22 |
|
KHB915F |
965x660x220 |
915x610x69 |
1500 |
500x250 |
550x300 |
1025x720x268 |
≈24 |
|
KHB968F |
1018x534x220 |
968x484x80 |
1700 |
500x200 |
550x250 |
1078x594x268 |
≈32 |
|
KHB1220F |
1270x660x220 |
1220x610x69 |
2000 |
500x200 |
550x250 |
1330x720x508 |
≈34 |
|
KHB945F |
995x680x220 |
945x630x80 |
2150 |
500x250 |
550x300 |
1055x740x578 |
≈32 |
|
KHB1260F |
1310x680x220 |
1260x630x80 |
3000 |
600x250 |
650x300 |
1370x740x578 |
≈37 |
